Vermeer RTX200 36″ Trencher
General Dimensions and Weights
| Length (Tractor with Tires) | 83 " | 210.8 cm |
| Width (Over Rubber Tracks) | 35 " | 88.9 cm |
| Width (Over Rubber Tires) | 35 " | 88.9 cm |
| Height | 46 " | 116.8 cm |
| Weight (Tractor with Tires) | 940 lbs | 426.4 kg |
Engine Option One
| Make and Model | Kohler CH640 | |
| Fuel Type | Gasoline | |
| Horsepower at Maximum RPM (Gross) | 20.5 hp | 15.3 kw |
| Displacement | 41.1 cu-in | .7 L |
| Cooling Medium | Forced air | |
| Aspiration | Natural |
Hydraulic System
| Attachment Pump Relief Pressure (Trencher/Forward) | 2500 psi | 172.4 bar |
| Ground Drive Pump Relief Pressure Forward/Reverse | 2400 psi | 165.5 bar |
| Ground Drive Pump gpm at Maximum Engine RPM | 5.4 gpm | 20.4 L/min |
| Hydraulic Supply Filter Rating | 100 mesh strainer | |
| Attachment Pump gpm at Maximum Engine RPM | 10.3 gpm | 39 L/min |
| Hydraulic Return Filter Rating | 3 micron |
Capacities
| Fuel Tank | 2.5 gal | 9.5 L |
| Hydraulic Tank | 10.8 gal | 40.7 L |
| Hydraulic System | 11.3 gal | 42.6 L |
| Engine Oil | .5 gal | 1.9 L |
Ground Drive
| Ground Drive Type | Hydrostatic | |
| Clutch Type | none | |
| Maximum Forward Transport Speed at Full Throttle | 3.1 mph | 5 km/h |
| Maximum Reverse Transport Speed at Full Throttle | 1 mph | 1.6 km/h |
